| Basic Parameters |
| Type | Android Industrial Printer Handheld Terminal |
| CPU | 2.5GHz |
| Graphics Processor | Mali-t720-MP2 |
| Storage | 2G LPDDR3 RAM+16G EMMC ROM |
| OS | Android 7.1 |
| Color | Black |
| Display | 5'' High-resolution , 1280*720 DPI , 5 Points-touch Screen; Corning Gorilla Glass |
| Fingerprint Sensor | TCS 1 |
| Thermal Printer | 2''384 thermal print head , print speed: 20mm/s |
| Communication | GSM:850/900/1800/1900 , WCDMA:B1/B2/B5/B8 , TDS-CDMA:B34/B39 LTE-TDD:B38/B39/B40 , LTE-FDD:B1/B3/B7/B8/B20 |
| GPS | (Built-in) GPS+BDS , Support A-GPS , High Accuracy Position |
| Port | Micro USB2.0, support OTG |
| Memory Interface | TF Card(Micro SD Card) ,128 G |
| Power Adaptor | Input: 100-240V, 50/60HZ 300mA Output: 5V, 2A |
| Bluetooth | Bluetooth 4.0 , Support BLE |
| Audio | Built-in Speaker , MIC , Handset , 3.5mm Headphone Jack |
| WLAN | 802.11a/b/g/n |
| Camera | 8.0 Mega Pixel Rear Camera; 2.0 Mega Pixel Front Camera; Auto Focus; with Led Light |
| Battery | Li-Polymer 4000mAh |
| Standby Time | ≧100h |
| Duration | ≧8 hours ( full function ) |
| IOT Functions(RFID, Barcode) |
| 1D Barcode | UPC / EAN , Bookland EAN , UCC Coupon Code , ISSN EAN , Code 128 , GS1 - 128 , ISBT128 , Code39 , Trioptic Code39 , Code32 ,Code93 , Code11 , Interleaved 2 of 5 , Discrete 2 of 5 , Codabar , MSI , Chinese 2 of 5 , Korean 3 of 5 , Matrix 2 of 5 , Inverse 1D , GS 1 DataBar , Composite Codes . etc |
| 2D Barcode | PDF417, MicroPDF417, Data Matrix, Data Matrix Inverse, Maxicode, QR Code, MicroQR, QR Inverse, Aztec, Aztec Inverse, Han Xin, Han Xin Inverse, etc. |
| RFID | * Fully support NFC, 14443A/B,15693 Protocol, Reading Distance 2cm~5cm, reading position, battery cover. *Support UHF RFID (920MHz-925MHz) , EPC C1/G2, ISO 18000-6C Protocol |
| Working Environment |
| Operation Temperature | -20℃ ~60℃ (Thermal Printer 0℃ ~ 40℃) |
| Storage Temperature | -30℃ ~70℃ |
| Humidity | 0~95% (Non-condensing) (Thermal Printer 20% ~ 85℃) |
